DSO502 user manual. click here
system requirements
| item |
deion |
| CPU |
>2.0 G |
| RAM |
>1 G |
| OS |
Windows XP / Windows 7 |
| SDK |
.net framework 2.0 |
| USB hub |
USB 2.0 |
| temperature |
0 ~ 40 centigrade |
| item |
index |
| bandwidth |
20M HZ |
| vertical resolution |
8 bit |
| voltage input range |
-5v~5v, could be expanded to -50v~50v by a X10 probe |
| DC accuracy |
+/- 1% |
| coupling type |
DC, AC, GND |
| trigger edge |
rising edge, falling edge or none |
| trigger channel |
channel 0 or channel 1 |
| trigger level |
could be set by mouse dragging |
| trigger mode |
auto, normal, single |
| measurement |
Max value, Min value, peak-peak value, frequency, average value |
| zoom in |
yes |
| cursor measurement |
yes |
| PC interface |
USB 2.0 |
| power supply |
derived from USB hub by USB cable |
| input resistance |
1M / 25pf |
| Max sample rate |
50M SPS |
| storage depth |
4k byte |
| channel number |
dual channel |
| power consumption |
< 2 w |
| weight |
<300g |
| OS support |
Windows XP, 2000,2003,Vista,Win7, 32bit &64bit |
| size |
10cm*6cm*2.5cm |
| extension |
none |
