The Latest Honda Motorcycle Tester for OBD Tool

1. What is the minimum system requirement to run the software ?

All computers running Windows (any version) and having a USB
port will do. The minimum screen resolution is 1024x600.

2. How to use the tool ?

- Have the ignition key in OFF position.
- Connect the OBD tool connector to the 4-pole RED DLC plug of
the bike, and connect the USB plug to your Windows PC.
Warning: Never connect the OBD tool connector to a bike plug other than the RED plug.
- Start the OBD tool application.
- Select neutral, turn ignition On and have the engine stop switch
in RUN position.
- Press the "Connect" button. The engine parameters must be
shown on the screen.
- Start the engine if you wish to inspect parameters with the
engine running.

3. Some parameters do not show any value, why ?

This means your vehicle does not have such kind of sensor, or that
sensor data is not available through the OBD interface on your bike.

4. Can I get some deion on the sensors ?

Yes, move your mouse on the sensor name and wait a second, an
infotip will appear.
