1. Processor：32 bit ARM Cortex M3 kernel CPU
2. LCD screen：2.8 inch TFTLCD
3. Resolution：320*240
4. Number of channels：1 channels
5. Input impedance：>1M Europe
6. The reference waveform output：10HZ ~ 1MHZ
7. The measurement bandwidth：0 ~ 4MHZ
8. The maximum sampling rate：50MS/s
9. The storage depth：4K byte
10．Maximum input voltage：40V ( x1 probe ), 400V ( X10 probe )
11. Trigger type：rising edge, falling edge trigger trigger
12. Scan mode：automatic scan, plain scan, single scan and random scanning
13. Measurement parameters：voltage deviation, time difference, frequency of signal, signal cycle, signal duty
ratio, AC peak-to-peak value, effective value, average value of AC and DC average value
14. Waveform storage capacity：4M
15. Waveform storage quantity：temporary limit 256
16. Power supply：built-in rechargeable lithium battery 3.7V, can also use the power supply for the USB 5V
