Function:

* Smart vehicle  Program

* Charging dedicated power

* Input voltage 220V only, Output Voltage 14V/120A.

* High temperature alarm.

* Intelligent charger for motor vehicles starter battery

* Extensive protection functions and self-protection functions

* Short circuit and reverse polarity protection

Applicable models: Volvo, Porsche, VW, Audi, BMW, Mercedes-Benz, G-eneral Motors Etc.

Automotive Programming Dedicated Power Output Characteristics

DC voltage: 14V

Rated current: 0-120A (±5A)

Rated maximum power: 1500W

Ripple and noise: 100mVp-p

Automotive Programming Dedicated Power Input Characteristics

input voltage: AC220V±15%,

Frequency range: 40-60HZ

Power Factor: 0.95

Efficiency: 85%

Automotive Programming Dedicated Power Protection Features

Overload: 90-110% of rated output power

Output voltage/ A : 14V /120A

Working temperature: -40°C±85°C

Safety: UL60950, TUV EN60950-1

Withstand voltage: I / P-O / P: 3KVAC I / P-FG: 1.5KVAC

Insulation resistance: I / PO / P, I / P-FG: 100M Ohms, 500VDC/25 C / 70% RH

EMC: Complies with EN55022, EN61000
